    Hydraulic Concrete Block Making Machines

    Hydraulic Concrete Block Making Machines
    Hydraulic Concrete Block Making Machines
    Send Inquiry
    Product Code : 860
    Price And Quantity
    • Minimum Order Quantity
    • 1 Unit
    • Price
    • 1.7 Lakh INR
    Product Specifications
    • Body Material
    • Stainless Steel
    • Type
    • Pipe
    • Force
    • Hydraulic Kilonewton (kN)
    Product Description

    Hydraulic Concrete Block Making Machines

    Clients can avail from us an excellent range of Hydraulic Concrete Block Making Machines. The offered machines are manufactured using supreme grade components with the help of cutting-edge technology by our skilled team of professionals. Our offered machines are used for making different concrete blocks and are highly demanded in construction industry. To meet the extensive needs of the clients, we offer these Hydraulic Concrete Block Making Machines in varied technical specifications at affordable price.

    Products Features:

    • Compact design
    • Trouble free functionality
    • Low power consumption
    • Negligible maintenance

    Technical Specifications:

    860MODEL

    SINGLE VIBRATOR

    DOUBLE VIBRATOR

    TRIPLE VIBRATOR

    Total Power 3 Phase 415 V

    5 H.P

    6.5 H.P

    8 H.P

    Hydraulic Motor

    3 H.P 1440 rpm

    3 H.P 1440 rpm

    3 H.P 1440 rpm

    Vibrator Mould Motor

    1.5 H.P 2880 rpm

    3 H.P 2880 rpm

    3 H.P 2880 rpm

    Vibrator Ram Motor



    1.5 H.P 2880 rpm

    Travel Motor

    0.5 H.P 1440 rpm

    0.5 H.P 1440 rpm

    0.5 H.P 1440 rpm

    Weight without Mould & Ram

    1000 kg (approx)

    1150 kg(approx)

    1300 kg (Approx)

    Vibrations

    6000 Hz Amplitude Adjustable

    Operating Pressure

    140 kg/cm2

    Moulding Area

    860 x 600 mm

    Dimensions

    2000 x 1500 x 2000 mm

    Production Capacity

    40 - 50 Strokes / Hour


    400 x 100 x 200 mm 8 block/stroke - 2500 - 3200 / Shift


    400 x 150 x 200 mm 5 block/stroke - 1600 - 2000 / Shift


    400 x 200 x 200 mm 4 block/stroke - 1200 - 1600 / Shift

    Trade Information
    • Payment Terms
    • Cheque, Cash in Advance (CID), Cash Advance (CA)
    • Supply Ability
    • 5 Unit Per Month
    • Delivery Time
    • 1 Days
    • Main Domestic Market
    • All India
