Product Description
Facilitated by technically advanced production unit, we are manufacturing, exporting and supplying a precision engineered collection of Hydraulic Concrete Making Machine. The offered machine is widely used to make concrete for construction applications. We manufacture this machine using high grade components with the help of cutting-edge technology. Also, we test this machine upon a series of tests, ensuring its overall performance. Our prestigious clients can avail this Hydraulic Concrete Making Machine at industry leading price.
Product Features:
- High operational fluency
- Durable finish
- Low maintenance
- Precisely engineered
Technical Specifications:
860MODEL | SINGLE VIBRATOR | DOUBLE VIBRATOR | TRIPLE VIBRATOR |
Total Power 3 Phase 415 V | 5 H.P | 6.5 H.P | 8 H.P |
Hydraulic Motor | 3 H.P 1440 rpm | 3 H.P 1440 rpm | 3 H.P 1440 rpm |
Vibrator Mould Motor | 1.5 H.P 2880 rpm | 3 H.P 2880 rpm | 3 H.P 2880 rpm |
Vibrator Ram Motor | _ | _ | 1.5 H.P 2880 rpm |
Travel Motor | 0.5 H.P 1440 rpm | 0.5 H.P 1440 rpm | 0.5 H.P 1440 rpm |
Weight without Mould & Ram | 1000 kg (approx) | 1150 kg(approx) | 1300 kg (Approx) |
Vibrations | 6000 Hz Amplitude Adjustable |
Operating Pressure | 140 kg/cm2 |
Moulding Area | 860 x 600 mm |
Dimensions | 2000 x 1500 x 2000 mm |
Production Capacity | 40 – 50 Strokes / Hour |
| 400 x 100 x 200 mm 8 block/stroke – 2500 – 3200 / Shift |
| 400 x 150 x 200 mm 5 block/stroke – 1600 – 2000 / Shift |
| 400 x 200 x 200 mm 4 block/stroke – 1200 – 1600 / Shift |
